The 21,5″ Panel PC’s SAC21 are equipped with either a projected capacitive multi-touchscreen(PCAP) or a 5-wire resistive touch display. Both displays are embedded flush with the adjacent areas in a stainless steel front panel.
The processors Intel® Core™ i5-7300U with max. 3,5GHz or the Intel® Pentium® 4415U with 2,3GHz are for choice.
These systems contain a 12/24VDC power supply and a VESA 100 attachment.
21,5" IP66 stainless steel all in one PC
The 21,5″ Panel-PCs PPC21 p1 and p2 contain a projected capacitive LCD (PCAP) with full-HD resolution embedded flush with the adjacent areas in a stainless steel front.
The fan-less processors Intel® ATOM up to i7 are for choice. The computers are equipped with a 9-36VDC power supply. They may also be operated by Power over Ethernet (POE).
Panel PCs with different LCDs
These panel PCs now are populated with different displays embedded flush with the adjacent areas in a stainless steel front and a resistive- or PCAP touch screen.
The power supply 12/24VDC may also be operated by power over Ethernet.
7"- and 10" Tablet / Handheld systems for rough industrial applications, i. e. production data acquisition or Point of sale operation (POS)
The fail-safe plastic housings of the tablets TAB07 and TAB101 got a shake-proof installation with rubber strengthened rough edges of the cage. They contain a multi-touch display covered by a ruggedized dragontrail glas. The processor Intel™ ATOM™ x5-Z8550 Quad Core™ got a clock frequency of 1,44GHz-2,4GHz.
The rechargeable battry pack will last for 8 hours. By means of a loading unit the TAB101 may be operated contionously for 24/7.
There are several enhancement options converting the TAB07 and TAB101 for a versatilely system.
RPi10 RFID PoE – Raspberry-Pi-3 PC with 10.1 “TFT, RFID and PoE (Power over Ethernet)
The robust aluminum housing of the industrial-Raspberry-Pi-3 PC RPi10-RFID-PoE contains a 10.1″ widescreen multi-touch LCD with a resolution of 1280×800 pixels. The Raspberry Pi 3B / 3B + with its ARM Cortex A53 with 4x 1.2GHz or 4x 1.4GHz is used as the CPU unit.
The RPi10-RFID-PoE has an input voltage of 36 to 75VDC, which is fed in via the LAN socket (Power over Ethernet) and has a VESA-75 attachment on the back. External power packs for different power supplies are available.
The integrated TWN4 Multitech RFID reader / writer supports the frequencies 125 / 134.2kHz and 13.56 MHz as well as all common transponders.
The standard housing color is RAL9005 (rear part) and natural aluminum for the front frame and can be changed according to customer requirements.
Also available with 09-36VDC and interface extensions as RPi-RFID
read more
RPi 10 Xtend – Raspberry-Pi-3 Panel-PC with PiXtend® v2-l and 10,1″ TFT
The rugged stainless steel housing of the industrial Raspberry Pi-3 Panel PC RPi10-Xtend includes a 10,1 “widescreen multi-touch LCD in an aluminum front with a resolution of 1280×800 pixels. The CPU unit is the Raspberry Pi 3B + with its ARM Cortex A53 with 4x 1.4GHz.
With the integrated I / O and interface extension PiXtend® v2-L from Qube Solutions, this Panel PC may be used as a programmable logic controller to be installed in consoles, cabinets or walls. It also includes a visualisation-, operation- and programming unit.
RPi 07 Xtend - Raspberry-Pi-3 Panel-PC with PiXtend v2-s and 7" TFT
The rugged stainless steel housing of the industrial Raspberry Pi-3 Panel PC RPi07-Xtend includes a 7 “widescreen multi-touch LCD in an aluminum front with a resolution of 800×480 pixels. The CPU unit is the Raspberry Pi 3B + with its ARM Cortex A53 with 4x 1.4GHz.
With the integrated I / O and interface extension PiXtend® v2-S from Qube Solutions, this Panel PC may be used as a programmable logic controller to be installed in consoles, cabinets or walls. It also includes a visualisation-, operation- and programming unit.
SAC15-RFID - 15" industrial all in one PC with RFID reader/writer
The rugged aluminum housing of the industrial-all-in-one PC SAC15-RFID contains a 15″ LCD with XGA resolution and a resisitive single touchscreen or a projected capacitive multi-touchscreen. Different processors like Intel® AtomTM N3160 / N3060 to core-i7 are available. The integrated TWN4 Multitech RFID reader / writer supports the frequencies 125 / 134.2kHz and 13.56 MHz as well as all common transponders.
The standard housing color is RAL9005 and may be changed according to customer’s requirements.
RPi 10 - Raspberry-Pi-3 PC with 10,1" TFT
The robust aluminium housing of the industrial PC Raspberry Pi-3 RPi10 contains of a 10,1″ multi-touch LCD (wide screen) with a resolution of 1024×600 pixel. The CPU board includes the newest Raspberry Pi version 3B with the ARM Cortex A53 running at a clock frequency of 4x 1,2GHz or 4x 1,4GHz.
The system needs an input voltage of 12 or 24VDC. Also there are external power supplies available for different voltages.
The RPi10 is equipped with a VESA-100 fastening to add a pivot arm or foot. The standard color of the rear housing is RAL9005 (black) and the front frame is natural aluminium; both being changeable upon customers demand.
RPi07 - Raspberry-Pi-3 PC with 7" TFT
The robust aluminium housing of the industrial PC Raspberry Pi-3 RPi07 contains of a 7″ multi-touch LCD (wide screen) with a resolution of 800×400 pixel. The CPU board includes the newest Raspberry Pi version 3B with the ARM Cortex A53 running at a clock frequency of 4x 1,2GHz or 4x 1,4GHz.
The system needs an input voltage of 12 or 24VDC. Also there are external power supplies available for different voltages.
The RPi07 is equipped with a VESA-75 fastening to add a pivot arm or foot; alternatively there is a holding clamp disposable for mounting in front panels. The standard color of the rear housing is RAL9005 (black) and the
front frame is natural aluminium;
both being changeable upon customers demand.
