SAC 17 – all-in-one PC with 17″ TFT

The SAC 17 contains a 17“ LCD, resolution SXGA (1280×1024 pixel), optional populated with[nbsp]a resistive touch screen. This display is inserted in a separate aluminium housing. The flat steel sheet computer housing (depth 98,5mm) may be equipped with 4 different SBCs :AMD® GX-210HA/GX-217GA/GX-420CA orIntel® i3/i5/i7.
For insertion of max. 2 enhancement boards there is an deep housing available (144,5mm).
2 power supplies are for choice: 12/24 VDC or 90-264VAC.
Both powder coatedcomputer housings contain a VESA mount (75mm) to add a desktop stand or a wall mount arm.

Price on request

Out of stock

Additional information

CPU

AMD® GX-210HA (2x 1,0GHz), GX-217GA (2x 1,66GHz) oder GX-420CA (2x 1,0GHz), Intel® i3/i5/i7 LGA1155 CPUs (z.B. i3-2120, i5-2400 oder i7-2600)
Display

TFT 17" SXGA
Touch­screen

Resistiv; 4-Draht
Memory

max. 16GB-DDR3
Ethernet

2x 10/100/1000Mbps
Seriell / USB

1x RS232; 2x USB
Mass memory

Industrial mSATA SLC/MLC Module or 2,5" HDD/SSD
Extension

WLAN; RS232/422/485; USB; Audio; 2x PCI; DVD
Operating system

Microsoft Windows XP Professional, Microsoft Windows XP embedded
Dimensions

385x332x90mm, 385x332x135mm (with PCI-extensions and CD/DVD-drive)
Weight

15,0 kg
Power supply

90-264 VAC, 12/24/48 VDC
Option

75mm VESA mounting or stand with tilt mechanism
